Wall Mounted 5.12kWh 100Ah 48V Solar Storage Battery Powerwall Home Battery

Brand Name : TINKO/OEM

Model Number : KT-48100G

Certification : CE/ROHS/MSDS/UN38.3

Place of Origin : China

MOQ : 1PC

Price : Negotiable

Supply Ability : 100pcs/day

Packaging Details : 1pc/parer carton

Cycle Life : >6000 times

Shell Material : Steel

Size : 1010*568*65mm

Weight : 66kg

Voltage : 51.2V

Installation : Wall-mounted

Usage : indoor、outdoor、solar syatem

Original : Dongguan, Guangdong

Contact Now

Wall-mounted Lithium-ion Energy Storage Battery





Product Description



LiFePO4 (Lithium Iron Phosphate) batteries are a type of lithium-ion battery known for their stability, safety, and good performance, they areideal for home energy storage paired with solar panels. TINKO storage battery are make by A+ level lifepo4 battery cell, through different pack way, their power rang from 5kWh to 51Kwh or even higher. The intelligent BMS system guarantees the security of electricity consumption. It circle life can up to 6000 times.





Technical Parameters























































Battery Pack



No.



Item



General Parameter



Remark



   1

Combination method



                    16S1P

   2

Rated Capacity



 Typical



100Ah

Standard discharge after Standard charge(for the whole battery pack)



Minimum



100Ah
   3



Factory Voltage



               51V-53V(40-60%)

Operation Voltage



   4



Voltage at end of

Discharge





   40V

Discharge Cut-off Voltage



   5



Charging Voltage



                     56-58V





   6





Internal Impedance









≤40mΩ

Internal resistance measured at AC 1KHZ after 50% charge



Should use those battery which finished within 1week after shipment and cycles less than 5times to do the measurement





   7



Standard charge



Constant Current 20A

Constant Voltage see No.5

0.02CA cut-off



Charge time : Approx 5 . 0 h

Limiting current



80A

   8

Standard discharge



Constant current:20A end voltage see NO.4

   9

Max Continuous Charge Current



100A



≥10ºC

  10

Max Continuous Discharge Current



                 100A

                     ≥10ºC

   11

Operation Temperature

Range



 Charge : 0~55℃

60±25%R.H.

Bare Cell



Discharge  : -20~60℃





  12



Storage Temperature Range



   Less than 12 months :- 10~35℃







60±25%R.H.at the shipment state

 Less than 3 months: - 10~45℃



Less than 7 day : -20~65℃



  13       Dimensions  1010*568*63.5(79)mm Include Bracket
  14       Weight  Approx :66kg



Wall Mounted 5.12kWh 100Ah 48V Solar Storage Battery Powerwall Home Battery
