High Energy Density 12V 200AH Battery As A Replacement For The Lead Acid Battery

Brand Name : TINKO/OEM

Model Number : KTQG - 48200

Certification : CE/ROHS/MSDS/UN38.3

Place of Origin : China

MOQ : 1PC

Price : Negotiable

Supply Ability : 100pcs/day

Packaging Details : 1pc/parer carton

Battery Type : Lifepo4

Voltage : 12V

Capacity : 200AH

Weight : 25kg

Size : 635*355*348mm

Model : KTQG-12200

Package : Paper Carton

Original : Dongguan, China

Contact Now



12V 200Ah LiFePO4 Battery with Intelligent BMS, Ideal for Residential solar energy storage and backup power





Product Description

TINKO 12V 200Ah LiFePO4 battery pack made by A grade lifepo4 battery cell which is more stable and have a higher energy density. They are widely used in many areas such as RV, Solar system, Household Battery back up, Marine, Off-Grid and Electric Scooter, Electric Handicap and so on. Each battery has intelligent BMS to ensure safe and efficient operation.





Product Parameters



NO



Projects

Specification

Remark



Cell unit parameter
1

Battery types and materials



 LiFePO4
2

Rated voltage/capacity



 3.2V / 100Ah
3

Single battery voltage range



 2.5V～3.65V
4

Single battery weight



 1.9Kg
5

The battery internal resistance



 ≤ 0.3mΩ
6



Battery size

 50*160*116mm
Battery parameter
1

Rated voltage



 12.8V
2



Rated capacity



 200Ah
3



Battery pack voltage range



 10～14.6V
4



Total Power

 2560Wh
5



Combination

 4S2P
6



Insulation resistance test value

 ≥1.2MΩ
7



Operating temperature

Charging 0 ~ 55℃；

Discharging -20 ~ 60℃


8



Standard charging current

 0.5C
9



Quick charging current

 1.0C
10



Standard discharge current

 1.0C
11



Maximum continuous discharge current

 2.0C
12



Gross weight

 Around 20KG
13



Ambient relative humidity

 20-85%RH
14



Battery size

 483*170*240mm(±2mm)
